Department of Civil Engineering


Major facilities available in Civil Engineering Department

Server, 25 High End Pentium IV Desktops, Laptop and Desktop to every Faculty Member, Color and A3 size Laser Printer, Plotter, Scanner, Office Suites, OS, Programming Tools and Software.

Ion Analyzer with ion selective electrode, UV-Visible Spectrophotometer, Atomic Absorption Spectrophotometer, Ozone Generator, Auto Exhaust Analyzer, Particle size analyzer, Toxic gas analyzer, High volume sampler Diesel Smoke Meter, Noise Meter, Potable lab for complete physical and chemical analysis of water & waste water.

Build Auto Reduction, Digital Planimeter, Total Station, Self Reduction Theodolite, Electronic Distance Measuring Instrument, GPS.

Nuclear Density Gauge, CBR Apparatus, Digital Benkelmen Beam, Core Cutter, Marshall Apparatus, Roughometer, Bump Integrator & Viscometers.

DISA Hot Wire Anemometer, Wind Tunnel, Rigid and Tilting Bed Flumes, Francis Turbine, Pelton Wheel Turbine, Centrifugal Pump, Kaplan Turbine./p>

Digital Camera, Mapping Software such as ArcGIS University Education Kit with extensions, GeoMedia Professional, GRID, ERMapper, AutoCAD Educational Solution Set (Civil Engineering), Groundwater Modelling System (GMS), Watershed Modelling System (WMS).

Clinometer, Microscope, Hardness Box, Samples of Rocks.

Soil Drilling, Sampling & SPT Machine, Direct Shear Box test apparatus 2 kN, Triaxial test, Un-Confined compressive strength, Static cone penetrometer 100 kN capacity Engine Driven, Plate load test, Direct Shear Box test setup for rocks, Vane Shear Test Setup.

The laboratory is one of the largest laboratories for evaluation of concrete durability and is also equipped with a 42 m long Gantry Girder with a 7.8 m span for shifting heavy equipments/specimens. Some of the important equipments are ???Electronic Universal Testing Machine, Rebound Hammer, Digital Compressive Testing Machine, Ultra-sonic Pulse Velocity Apparatus, Concrete Core Cutter, Carbonation Chamber, Autoclave Machine, Abrasion Testing Machine, Water Permeability Apparatus (DIN 1048), Autoclam Permeability System, Freeze-thaw Chamber, Salt Spray Chamber, Chloride Ion Diffusion Set-up, Corrosion Monitoring System, Vacuum Impregnation Machine, and Temperature controlled curing tanks.

The Lab has an electrodynamics shaker of 600 kg(f) pay load capacity and maximum acceleration up to 75g, and a frequency range of 1 to 3500Hz, with microprocessor controlled data acquisition (accelerometers, having frequency range of 1Hz to 6kHz, having nominal sensitivity of 10 to 30 pC/g) and control system. Besides that the Lab has two horizontal and one vertical electromechanical shaker, vibration absorber and various size building models meant for imparting fundamental understanding of concepts of structural dynamics.
